Pulsarlube BT
De Pulsarlube BT is een automatische elektromechanische smeerunit met Bluetooth.
Ontdek meer over de Pulsarlube BT
Product bestellen
Enhanced User-Friendliness
Eenvoudig controleren via je mobiele telefoon van nabijgelegen Pulsarlube BT units
Mogelijk om instellingen te veranderen tijdens bedrijf van de smeerunits
Integrated DB Management
Eenvoudig delen van data tussen verschillende apparaten
Safe Working Environment
Op afstand controleren van nabijgelegen smeerunits welke op gevaarlijke en moeilijkbereikbare locaties geinstallaeerd zijn.
Service Pack
Besparingen door gebruik te maken van vervangbare vetpatronen en batterijen (Service Packs)
Pulsarlube BT Series 60, 120, 240
De Pulsarlube BT is een automatische smeerunit met Bluetooth die via een app op een mobiel apparaat kan worden bewaakt en geregeld binnen Bluetooth-bereik (5~20 m), zonder fysieke toegang tot de smeerunits.
Smeerunits worden in de app herkend zolang ze in het Bluetooth-detectiebereik zijn, wat het vinden van smeerunits, het bewaken van de status en het veranderen van instellingen heel eenvoudig maakt. De gegevens in de mobiele app worden gedeeld met onze webapplicatieserver en kunnen in .csv- of .txt-formaat worden gedownload voor optimale monitoring.
Dankzij de BLE (Bluetooth Low Energy)-technologie verbruikt de Bluetooth-module weinig energie en kan de smeerunit betrouwbaar werken, zelfs als een batterijpakket wordt gebruikt. De unit heeft een IP65-classificatie en kan dus buiten worden geïnstalleerd. Hij is beschermd tegen stof en waternevel.
Door Bluetooth-technologie toe te passen, is de Pulsarlube BT ontwikkeld om in uw smeerbehoeften te voorzien met een ongekend technologisch gemak.
Product dimensies
- BT60: Ø91(3.6″) x 181mm(7.13″)
- BT120 : Ø91(3.6″) x 181mm(7.13″)
- BT240 : Ø91(3.6″) x 208mm(8.19″)
Technische specificaties
| Specificatie | Waarde |
|---|---|
| Grease Pouch Capacity | 60ml / 120ml / 240ml (pre-set) |
| Power Supply | DC 4.5V Battery Pack |
| Operating Pressure | 30~60bar (435~870psi) |
| Operating Temperature | Standard Alkaline Battery : -5˚C ~ 60˚C (23°F ~ 140°F) |
| Operating Temperature | Optional Lithium Battery : -20˚C ~ 60˚C (-4°F ~ 140°F) |
| Dispensing Periods | 1 ~ 12 month |
| Remote Installation | Max. 6m (20ft) with Ø6 tube |
| Multi-Point Installation | Max. 3m (10ft) with Ø6 tube (Up to 8 lube points) |
| IP Code | IP65 |
| Product Certifications | CE / KC / FCC / RCM / NCC / SRRC / SIG |
| Detection Range | 5 ~ 20m depending on installation environment |
| Bluetooth Specifications | Bluetooth 4.1 (class 2) |
| Packaging | 10 Units/Case |
Productcertificaten
| Certificaat | Waarde |
|---|---|
| IP code | IP65 |
| KC | R-RMM-kLT-BT240 |
| CE | CE |
| FCC | 2APJH-BT240 |
| RCM | RCM-001311 |
| NCC (60) | CCAH19LP0122T6 |
| NCC (120) | CCAH19LP0121T4 |
| NCC (240) | CCAH19LP0120T2 |
| SRRC (BT60 CMIIT ID) | 2019DJ0846 |
| SRRC (BT120 CMIIT ID) | 2019DJ0847 |
| SRRC (BT240 CMIIT ID) | 2019DJ1090 |
| SIG | D042809 |
Snel downloaden
Handleiding in het Engels
Handleiding app (iOS)
Handleiding app (Android)
Flyer in het EngelsFlyer in het Engels
Accesoires
Reducer, 3/8Part No.: A001
Reducer, 3/8Part No.: A002-S
Reducer, 3/8Part No.: A002
Socket, 1/4Part No.: A011
Socket, 1/8"F x 1/8"F Adaptor (Brass)Part No.: A012
90° Elbow, 1/4"F x 1/4"F Adaptor (Brass)Part No.: A019
90° Elbow, 1/8"F x 1/8"F Adaptor (Brass)Part No.: A020
90° Elbow, 1/4"M x 1/4"F Adaptor (Brass)Part No.: A021
90° Elbow, 1/8"M x 1/8"F Adaptor (Brass)Part No.: A022
45° Elbow, 1/4"M x 1/4"F Adaptor (Brass)Part No.: A023
45° Elbow, 1/8"M x 1/8"F Adaptor (Brass)Part No.: A024
Pipe, 1/8"M x 1/8"M x 50mm for divider block (Steel)Part No.: A106
Pipe, 1/8"M x 1/8"M x 100mm for divider block (Steel)Part No.: A107
Pipe, 1/8"M x 1/8"M x 150mm for divider block (Steel)Part No.: A108
Pipe, 1/8"M x 1/8"M x 200mm for divider block (Steel)Part No.: A109
Pipe, 1/4"M x 1/4"M x 50mm for divider block (Steel)Part No.: A121
Pipe, 1/4"M x 1/4"M x 100mm for divider block (Steel)Part No.: A122
Pipe, 1/4"M x 1/4"M x 150mm for divider block (Steel)Part No.: A123
Pipe, 1/4"M x 1/4"M x 200mm for divider block (Steel)Part No.: A124
Distribution Tubing, O.D. 5/16" (8mm) Urethan Tubing, 3ft Pre-filled with (Grease Type)Part No.: A212-1
Tube Fitting, Push-In Type, PC8-PT1/8"MPart No.: A239
Mounting Bracket, "L" ShapePart No.: B002
Self Drilling Screw, #8 x 20Part No.: B051
WasherPart No.: B057
Thread Converter, PT1/8"F x NPT1/8"M (Brass)Part No.: A243
Toepassingen
Cement
- Blowers
- Conveyors
- Pumps
- Electric Motors
Cooling tower
- Pumps
- Fans
- Blowers
Steel industry
- Water Pumps
- Boilers
- Conveyors System
- Electric Motors
Directe montage installatie
Reducer
| Type | Waarde |
|---|---|
| A001 | Reducer, 3/8″F X 1/4″M Adaptor (Brass) |
| A002 | Reducer, 3/8″F X 1/8″M Adaptor (Brass) |
| A003 | Reducer, 3/8″F x 1/8″M Adaptor (Steel) |
45˚ Elbow
| Type | Waarde |
|---|---|
| A023 | 45° Elbow, 1/4”M X 1/4”F Adaptor (Brass) |
| A024 | 45° Elbow, 1/8”M X 1/8”F Adaptor (Brass) |
90˚ Elbow
| Type | Waarde |
|---|---|
| A019 | 90° Elbow, 1/4”F X 1/4”F Adaptor (Brass) |
| A020 | 90° Elbow, 1/8”F X 1/8”F Adaptor (Brass) |
| A021 | 90° Elbow, 1/4”M X 1/4”F Adaptor (Brass) |
| A022 | 90° Elbow, 1/8”M X1/8”F Adaptor (Brass) |
Socket + Pipe + Reducer
| Type | Waarde |
|---|---|
| A011 | Socket, 1/4″F x 1/4″F Adaptor (Brass) |
| A012 | Socket, 1/8″F x 1/8″F Adaptor (Brass) |
| A121 | Pipe,1/4”M X 1/4”M × 50mm (Steel) |
| A122 | Pipe,1/4”M X 1/4”M × 100mm (Steel) |
| A123 | Pipe,1/4”M X 1/4”M × 150mm (Steel) |
| A124 | Pipe,1/4”M X 1/4”M × 200mm (Steel) |
| A106 | Pipe, 1/8″M x 1/8″M x 50mm for divider block (Steel) |
| A107 | Pipe, 1/8″M x 1/8″M x 150mm for divider Pipe, 1/8″M x 1/8″M x 100mm for divider block (Steel) |
| A108 | Pipe, 1/8″M x 1/8″M x 150mm for divider block (Steel) |
| A109 | Pipe, 1/8″M x 1/8″M x 200mm for divider block (Steel) |
Single point remote installation
Kit No. 2000RC-1
| Type | Waarde |
|---|---|
| A005 | Reducer, 1/4″F x 1/8″ M Adaptor (Brass) |
| B002 | Mounting Bracket, “L”Shape |
| B051 | Self Drilling Screw, #8ⅹ20 |
| B057 | Washer |
| A012 | Socket, 1/8”F x 1/8”F Adaptor (Brass) |
| A239 | Tube Fitting, Push-In Type, PC8-PT1/8″M |
| A212-1 | Distribution Tubing, O.D. 5/16″(8mm). Urethan Tubing, 3ft Pre-filled with (Grease Type) |
| A243 | Thread Converter, PT1/8″F X NPT1/8″M (Brass) |
Note : For remote installation using a tube, use an 8mm O.D. (5/16″) tubing pre-filled with the same or compatible grease as the grease contained in the unit. Recommend using under short dispensing period settings due to powerful dispensing pressure.
Multi-Point installation
Electromechanical Products using a divider block ( up to 8 points )
